Gobius C, stepless measurement, 0-100%, version 3.0

This new version also measures petrol and diesel tanks.

$296

SKU: 970526 Category:

Plug and play installation. No disassembly of the tank is needed. Measures from the top, never risk of leakage. Complete system, everything included; sensor, cable, 3M cleaning wipe and an extra 3M sensor tape. Handles voltage of 12-24 Volts. The sensor is mounted in the same simple way as other Gobius products, but on the top of the tank. Max. tank depth is 2 meters. Can be connected to control systems and analog instruments such as KUS, VDO, WEMA, Faria (10-180 Ohm, 240-33 Ohm, 4-20 mA and 0-5 V).
In addition, there are two individual on/off alarm outputs to signal when the tank is empty and full. Installation is done from your phone via Bluetooth. The app is available in English, French, German, Italian, Norwegian, Spanish and Swedish.

General information

  • Suitable for all types of fluids
  • Plug and play installation
  • Multi-language support
  • All settings are done automatically
  • Built-in Tank Calculator
  • Built-in sea wave motion reduction
  • No need for removing the tank
  • Reading through plastic tank
  • No tank wall thickness limit (plastic)
  • Adapted for standard holes in metal tanks
    ( 1,25″ SAE 5)
  • No cleaning inside the tank is needed
  • No maintenance

Measurement functions

  • Measuring range, 20-2000 mm
  • Tank depth: Max 2 meters (78 inches)
  • Tank depth: Min 0,2 meters (7,8 inches)
  • Measuring interval, 1 second
  • Resolution: 1 mm
  • Accuracy: +/- 2-3 mm

Tank Geometries

  • Rectangular
  • Irregular
  • Vertical circular
  • Horizontal circula

Technical description

  • Input voltage, 9-29 V DC
  • Connector, female 8 pins
  • Two digital outputs (level alarms)
  • 4-20 mA (galvanically insulated)
  •  Outputs, 10-180 & 240-33 Ohm
  • Output, 0-5 V
  • Sensor LED, shows active/measuring
  • Power consumption, 10 mA
  • Built-in Bluetooth, version 5.0
  • Built-in temperature sensor
  • Built-in accelerometer
  • Built-in micro radar sensor
  • Max voltage: 29 V
  • Max current: 500 mA
  • Bluetooth turn on/off

Sensor Facts

  • Weight, 65 gram
  • Dimensions, high 65 mm, width 95 mm
  • Sensor height incl adapter metal tank, 75 mm
  • Cable length, 1 m
  • Connector on the sensor
  • Sensor material, ABS
  • Color, orange
  • Bluetooth, version 5.0
  • Water proof (IP66)

Software

  • App for iOS, Android phones and Windows PC
  • Multi-language support, Danish, English,
    Finnish, French, German, Italian, Norwegian,
    Spanish, and Swedish
  • Installation / change / removal
  • Correct level calculation, incl % and liters
  • Bluetooth, version 5.0
  • Turn on/off Bluetooth after 10 sec.
  • Two digital outputs, four states
  • Display on the phone
  • Built-in test functions
  • Built-in supportfunction

See also Gobius C site.
